LED Railway Frieght Yard Lighting
Compose of 2 kinds of lamp, first is long distance lighting, second is short distance lighting.

Specifications
Model BOSS-FY-44 BOSS-FY-105 BOSS-FY-92
Application Short distance lighting Long distance lighting
Material Aluminum die casting lamp and luminaire as one, surface anodizing, can use more than 10 years.
Protection Level IP65
Shock Proof Protection Level Grade I
Working Environment -30°C~+40°C
Input Voltage AC160V~AC250V (wide voltage area, suitable for many practical terms).
Luminaire Lifespan 50,000 hours, light depreciation less than 30%, (more than 10 years usage, 12 hours per day)
Color Temperature Can be customized between 3500~7000K
CRI 75~80
Power 44W 105W 92W
Luminious Flux 1700~2000lm 4000~4600lm 3500~4000lm
Breathing System No need
Size 436mm(W) x 200mm(H) x 62mm(D) 605mm(W) x 372mm(H) x 94mm(D)
Weight 4~4.5kg 7~8kg
